Micom P634 - Page 632

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
DTOC1: Starting I>>>
035 110
0: No
[spacer]
DTOC1: Trip signal tI>
035 114
0: No
[spacer]
DTOC1: Trip signal tI>>
035 115
0: No
[spacer]
DTOC1: Trip signal tI>>>
035 116
0: No
[spacer]
DTOC1: Starting Ineg
036 144
0: No Fig. 3-110, (p. 3-156)
[spacer]
DTOC1: Starting Ineg>
036 145
0: No Fig. 3-110, (p. 3-156)
[spacer]
DTOC1: Starting Ineg>>
036 146
0: No Fig. 3-110, (p. 3-156)
[spacer]
DTOC1: Starting Ineg>>>
036 147
0: No Fig. 3-110, (p. 3-156)
[spacer]
DTOC1: tIneg> elapsed
036 148
0: No Fig. 3-110, (p. 3-156)
[spacer]
DTOC1: tIneg>> elapsed
036 149
0: No Fig. 3-110, (p. 3-156)
[spacer]
DTOC1: tIneg>>> elapsed
036 150
0: No Fig. 3-110, (p. 3-156)
[spacer]
DTOC1: Trip signal tIneg>
036 151
0: No Fig. 3-110, (p. 3-156)
[spacer]
DTOC1: Trip signal tIneg>>
036 152
0: No Fig. 3-110, (p. 3-156)
[spacer]
DTOC1: Trip signal tIneg>>>
036 153
0: No Fig. 3-110, (p. 3-156)
[spacer]
DTOC1: Starting IN>
035 111
0: No
[spacer]
DTOC1: Starting IN>>
035 112
0: No
[spacer]
DTOC1: Starting IN>>>
035 113
0: No
[spacer]
DTOC1: tIN> elapsed
035 117
0: No
[spacer]
DTOC1: tIN>> elapsed
035 118
0: No
P634 8 Information and Control Functions
8-94 P634/EN M/R-42-A // P634‑311‑653
