Micom P634 - Page 68

COMM1:
Select. spontan.sig.
[ 003 179 ]
64Z70FFA
COMM1:
Transm.enab.cycl.dat
[ 003 074 ]
COMM1:
Cycl. data ILS tel.
[ 003 175 ]
COMM1:
Delta V
[ 003 050 ]
COMM1:
Delta I
[ 003 051 ]
COMM1:
Delta f
[ 003 052 ]
COMM1:
Delta meas.v.ILS tel
[ 003 150 ]
COMM1:
Delta t
[ 003 053 ]
COMM1:
Contin. general scan
[ 003 077 ]
COMM1:
Line idle state
[ 003 165 ]
COMM1:
Baud rate
[ 003 071 ]
COMM1:
Parity bit
[ 003 171 ]
COMM1:
Dead time monitoring
[ 003 176 ]
COMM1:
Mon. time polling
[ 003 202 ]
COMM1:
Octet comm. address
[ 003 072 ]
COMM1:
Test monitor on
[ 003 166 ]
COMM1:
Name of manufacturer
[ 003 161 ]
COMM1:
Octet address ASDU
[ 003 073 ]
COMM1:
Spontan. sig. enable
[ 003 177 ]
Commun. interface
COMM1:
Sig./meas.val.block.
[ 037 075 ]
COMM1:
Sig./meas. block EXT
[ 037 074 ]
MAIN:
Prot. ext. disabled
[ 038 046 ]
COMM1:
Sig./meas.block.USER
[ 003 076 ]
COMM1:
Selected protocol
304 415
COMM1:
IEC 870-5-103
[ 003 219 ]
COMM1:
General enable USER
[ 003 170 ]
COMM1:
Command blocking
[ 003 174 ]
MAIN:
Test mode
[ 037 071 ]
1: Yes
0: No
0
1
C
C
C
C
1: Yes
0: No
0
1
COMM1:
-103 prot. variant
[ 003 178 ]
Fig. 3-7: Communication interface 1, settings for the IEC 60870‑5-103 interface protocol.
