Parameter Default Value
GOOSE Source
Parameters
Source Path
Information data attribute in the transmitting device.
GOOSE Identifier
ID of the GOOSE in the transmitting device.
Dataset Reference
Name of the dataset assigned to the GOOSE in the transmitting device.
Configuration Revision 0
Configuration revision status of the transmitting device.
Data Obj Index 1
Position index of the data object within the GOOSE.
Data Obj Type Unknown
Structure of the data object; possible settings:
●
Unknown
●
Boolean (logical value)
●
Int8 (Integer, with 8 digits)
●
Int16 (Integer, with 16 digits)
●
Int32 (Integer, with 32 digits)
●
UInt8 (Positive integer, with 8 digits)
●
UInt16 (Positive integer, with 16 digits)
●
UInt32 (Positive integer, with 32 digits)
●
Float (Floating-point number)
●
BStr2 (Binary state, with 2 digits)
●
SPS (Single-pole signal)
●
DPS (Two-pole signal)
Quality Obj Index 1
Distance of the quality descriptor to the data object if not preset. The quality of
the received information is to be tested if such has been configured.
