Parameter Default Value
GOOSE Source
Parameters
Source Path
Information data attribute in the transmitting device.
GOOSE Identifier
ID of the GOOSE in the transmitting device.
Dataset Reference
Name of the dataset assigned to the GOOSE in the transmitting device.
Configuration Revision 0
Configuration revision status of the transmitting device.
Data Obj Index 1
Position index of the data object within the GOOSE.
Default Input Value True
Default value for the information in case GOOSE receipt has failed:
●
False – not set
●
True – set
●
Last Known Value – retain last value received
●
Double Point: intermediate (00) – switching device in intermediate position
●
Double Point: Off (01) – switching device open
●
Double Point: On (10) – switching device closed
●
Double Point: Bad state (11) – switching device in intermediate position
