Micom P634 - Page 750

Parameter Address
[spacer]
SFMON: Output 30
098 053
[spacer]
SFMON: Output 30 (t)
098 054
[spacer]
SFMON: Output 31
098 055
[spacer]
SFMON: Output 31 (t)
098 056
[spacer]
SFMON: Output 32
098 057
[spacer]
SFMON: Output 32 (t)
098 058
[spacer]
These LOGIC outputs can be included in the list of warning signals by selection
at SFMON: Fct. assign. warning. The warning signals are also recorded
in the monitoring signal memory.
“Warning” output relay: Yes
“Blocked/faulty” output relay: –
[spacer]
SFMON: CB1 pos.sig. implaus
098 124
[spacer]
SFMON: CB2 pos.sig. implaus
098 125
[spacer]
SFMON: CB3 pos.sig. implaus
098 126
[spacer]
SFMON: CB4 pos.sig. implaus
098 127
[spacer]
The plausibility logic was triggered during the acquisition of the circuit breaker's
(CB) status signals.
“Warning” output relay: Yes
“Blocked/faulty” output relay: –
[spacer]
SFMON: CB1 faulty EXT
098 072
[spacer]
SFMON: CB2 faulty EXT
098 129
[spacer]
SFMON: CB3 faulty EXT
098 130
[spacer]
SFMON: CB4 faulty EXT
098 131
[spacer]
The external input CBF_1: CB faulty EXT has become active.
Device reaction: –
“Warning” output relay: Yes
“Blocked/faulty” output relay: –
[spacer]
SFMON: Unsuff. No. of ends
091 010
[spacer]
More ends have been simultaneously disconnected from the measurement than
is permitted. (Up to two ends can be disconnected simultaneously with the
P634.)
Device reaction: The P634 is blocked.
“Warning” output relay: Updating
“Blocked/faulty” output relay: –
P634 11 Troubleshooting
11-16 P634/EN M/R-42-A // P634‑311‑653
