15 Order Information
Module Configuration Variants
Order information MiCOM P634
Four Winding Transformer Differential Protection P 6 3 4 - 9 9 1 -311 -4xx -653 -7xx -46x -9x x -8xx
Basic device:
Basic device 84TE, pin-terminal connection,
7 -411
Basic device 84TE, ring-terminal connection,
8 -412
basic complement with 4 binary inputs, 8 output relays
and 6 function keys
Mounting option and display:
Surface-mounted, local control panel with text display
3
Flush-mounted, local control panel with text display
4
Surface-mounted, with detachable HMI
7
Flush-mounted,with detachable HMI
9
Current transformer:
Inom = 1 A / 5 A (T11...T14 / T21...24)
2)
9
Inom = 1 A
/ 5 A ( T 31 ... T 34 / T 41 …T 43 )
2)
9
Voltage transformer:
Vnom = 50 ... 130 V (1-pole)
1
Additional binary I/O options:
Without
0
With 1 binary module (add. 6 binary inputs and 8 output relays)
1
Power supply and additional binary I/O options:
VA , nom = 24 … 60 VDC
E
VA,nom = 60 ... 250 VDC / 100 ... 230 VAC
F
VA,nom = 24 ... 60 VDC and 6 output relays
G
VA,nom = 60 ... 250 VDC / 100 ... 230 VAC and 6 output relays
H
VA , nom = 24 … 60 VDC and 6 binary inputs and 3 output relays
J
VA,nom = 60 ... 250 VDC / 100 ... 230 VAC
K
and 6 binary inputs and 3 output relays
VA , nom = 24 … 60 VDC and 4 high break contacts
L
VA,nom = 60 ... 250 VDC / 100 ... 230 VAC and 4 high break contacts
M
Further add. options:
Without
0
With analog module
2
With binary module (add. 24 binary inputs)
4
With analog module and binary module (add. 24 binary inputs)
6
P634
P634/EN M/R-42-A // P634‑311‑653 15-1
