A4.1.1.5 Basic Application Functions
(See National Preface of EN 60870-5-101.)
Station Initialization (Station-Specific Parameter)
[✓] Remote initialization
General Interrogation (System- or Station-Specific Parameter)
[✓] Global
[✓] Group 1 [✓] Group 7 [✓] Group 13
[✓] Group 2 [✓] Group 8 [✓] Group 14
[✓] Group 3 [✓] Group 9 [✓] Group 15
[✓] Group 4 [✓] Group 10 [✓] Group 16
[✓] Group 5 [✓] Group 11
[✓] Group 6 [✓] Group 12
Addresses per group have to be defined.
Clock Synchronization (Station-Specific Parameter)
[✓] Clock synchronization
Command Transmission (Object-Specific Parameter)
[✓] Direct command transmission [ ] Select and execute command
[ ] Direct set point command
transmission
[ ] Select and execute set point command
[ ] C_SE ACTTERM used
[✓] No additional definition
[ ] Short pulse duration (Execution duration determined by a system parameter in the
outstation)
[ ] Long pulse duration (Execution duration determined by a system parameter in the
outstation)
[ ] Persistent output
Transmission of Integrated Totals (Station- or Object-Specific
Parameter)
P634
A4 Telecontrol Interfaces
A4-8 P634/EN M/R-42-A // P634‑311‑653
