Fault Indications in Monitor Direction
INF Description P634 Designations
(Address) Description
[ ] <64> Start / pick-up A
[ ] <65> Start / pick-up B
[ ] <66> Start / pick-up C
[ ] <67> Start / pick-up N
[✓] <68> General trip (036 071) MAIN: Gen. trip command 1
[ ] <69> Trip A
[ ] <70> Trip B
[ ] <71> Trip C
[ ] <72> Trip I>> (back-up operation)
[ ] <73> Fault location X in ohms
[ ] <74> Fault forward/line
[ ] <75> Fault reverse/busbar
[ ] <76> Teleprotection signal
transmitted
[ ] <77> Teleprotection signal received
[ ] <78> Zone 1
[ ] <79> Zone 2
[ ] <80> Zone 3
[ ] <81> Zone 4
[ ] <82> Zone 5
[ ] <83> Zone 6
[✓] <84> General starting (036 000) MAIN: General starting
[ ] <85> Breaker failure
[✓] <86> Trip measuring system A (041 002) DIFF: Trip signal 1
[✓] <87> Trip measuring system B (041 003) DIFF: Trip signal 2
[✓] <88> Trip measuring system C (041 004) DIFF: Trip signal 3
[ ] <89> Trip measuring system N
[ ] <90> Trip I>
[ ] <91> Trip I>>
A4 Telecontrol Interfaces P634
P634/EN M/R-42-A // P634‑311‑653 A4-13
