Version Changes
SFMON The configuration table of the user defined alarm
condition has been extended by the instantaneous and
timed outputs 30…32(t) of the programmable LOGIC:
●
(098 053) SFMON: Output 30 ~ (042 090)
LOGIC: Output 30
●
(098 054) SFMON: Output 30 (t) ~ (042 091)
LOGIC: Output 30 (t)
●
(098 055) SFMON: Output 31 ~ (042 092)
LOGIC: Output 31
●
(098 056) SFMON: Output 31 (t) ~ (042 093)
LOGIC: Output 31 (t)
●
(098 057) SFMON: Output 32 ~ (042 094)
LOGIC: Output 32
●
(098 058) SFMON: Output 32 (t) ~ (042 095)
LOGIC: Output 32 (t)
These logic outputs are included in the warning signals
by setting SFMON: Fct. assign. warning and they
are also recorded in the monitoring signal memory.
These signals can be used to create an alarm signal
under complex application conditions. This signaling
has no influence on the device's operation (i.e. no
warm restart or blocking).
Addendum:
As of version –605 the “memory function” for the
warning signal memory may be set. After the
associated timer stage has elapsed, a renewed
occurrence of a warning is processed the same way as
if it where a first occurrence.
P634 A5 P634 Version History
A5-6 P634/EN M/R-42-A // P634‑311‑653
