Version Changes
CBF_x Implementation of the new circuit breaker failure
protection function including a current reset criterion.
The number of availabe function groups corresponds to
the number of transformer ends, that is for the P634, 4
function groups are available.
LOC Because of the ordering option “detachable HMI” this
additional Device Identification parameter is now
available: LOC: Local HMI exists (221 099).
LOC, MAIN Respective binary signal inputs (if previously
unavailable) are assigned to all default reset functions.
These binary input functions are now available in the
configuration list for the two newly implemented group
resetting functions as well as the extended functional
assignment for the CLEAR key ('C'):
●
(005 248) MAIN: Fct.assign. reset 1
●
(005 249) MAIN: Fct.assign. reset 2
●
(005 251) LOC: Assignment reset key
Two menu jump lists may now be configured. These
menu jump lists make it possible to select individual
menu points (i.e. set values, counters, triggering
functions, event logs) in a freely definable sequence.
●
(030 238) LOC: Fct. menu jmp list 1
●
(030 239) LOC: Fct. menu jmp list 2
F_KEY The new control panel (HMI) is fitted with 6 freely
configurable function keys which may be used either as
switches or keys, and are password protected.
Because of this the function group F_KEY “Configurable
Function Keys” has been added.
P634
‑306/307
‑405/406
‑611-715
Release: 2007-06-12
Hardware
No changes.
Diagram
No changes.
Software
LOC
Bug fixing:
●
Reset functions configured to the CLEAR key ('C')
are now carried out correctly.
A system restart could previously occur when the
detachable HMI was disconnected.
P634 A5 P634 Version History
A5-14 P634/EN M/R-42-A // P634‑311‑653
