Version Changes
MAIN The following menu points are now available for each
parameter subset:
●
MAIN: Vnom prim. end a PSx
●
MAIN: Vnom prim. end b PSx
●
MAIN: Vnom prim. end c PSx
●
MAIN: Vnom prim. end d PSx
The parameter (003 030) has been renamed to MAIN:
Device on-line.
The following parameters are now available for status
signals from external devices:
●
MAIN: Sig. asg. CB1 open (021 017)
●
MAIN: Sig. asg. CB2 open (021 061)
●
MAIN: Sig. asg. CB3 open (021 063)
●
MAIN: Sig. asg. CB4 open (021 065)
●
MAIN: Sig. asg. CB1 closed (021 020)
●
MAIN: Sig. asg. CB2 closed (021 060)
●
MAIN: Sig. asg. CB3 closed (021 062)
●
MAIN: Sig. asg. CB4 closed (021 064)
Note:
These signal assignment parameters are visible in the
data model for 4 circuit breakers. However, they are
not implemented for the P634.
MEASI The result of the temperature measurement may now
also be read out as the maximum value since the last
reset operation (temperature T
max
).
INP The setting INP: Filter (010 220) is now available for
conformity with standard IEC 60255-22-7, class A.
FT_DA Correction:
The wrong internal timing where the parameter
FT_DA: Run time to meas. (004 199) could take on
the value “Overflow” has been corrected.
THRM1,
THRM2
Correction:
With the following menu points the step size for
temperature values has been reduced from 0.01 to
0.001:
●
THRM1: Object temp. p.u. 1 (004 205)
●
THRM2: Object temp. p.u. 2 (004 208)
●
THRM1: Coolant temp. p.u. 1 (004 206)
●
THRM2: Coolant temp. p.u. 2 (004 209)
P634 A5 P634 Version History
A5-18 P634/EN M/R-42-A // P634‑311‑653
