Microsens MS400870M Series User Manual

42
 Setting VLAN Port Egress mode in MVR Receive port. In a normal condition, Un-tag
multicasting stream forward to receive port. (Optional)
Limitation
 Receiver ports on a switch can be in different VLANs, but they should not belong to the
multicast VLAN.
 Do not configure MVR on private VLAN ports.
 MVR can coexist with IGMP snooping on a switch.
 MVR data received on an MVR receiver port is not forwarded to MVR source ports.
 MVR does not support IGMPv3 messages.
 MVR on IPv6 multicast groups is not supported.
Prompt
Command & Parameter
Description
Console(config-
mvr)#
mode <enable | disable>
To enable or disable MVR global setting
add <vlan_id> <rec_port_list>
<sor_port_list>
To add a MVR VLAN ID and specify its Receive
and Source Port.
<vlan_id>: 1~4094
<rec_port_list>: 1~26
<sor_port_list>: 1~26
For example:
Console(config-mvr)#add 4094 1-4,10-15,18,19 5-
9,16,17
delete <vlan_id>
To delete a registered MVR VLAN ID.
<vlan_id>: 1~4094
For example:
Console(config-mvr)#delete 4094
Console(config-
mvr-group)#
add <vlan_id> <ip> <ip>
To add a new MVR group and specify the
multicasting channel that would belong to MVR
VLAN.
<vlan_id>: 1~4094
<ip>: Specify the group range 224.0.1.0~238.
255.255.255
For example:
Console(config-mvr-group)# add 4094 224.0.1.0
238.255.255.255
delete <vlan_id> <ip> <ip>
To delete a registered MVR group.
<vlan_id>: 1~4094
<ip>: Specify the group range 224.0.1.0~238.
255.255.255
For example:
Console(config-mvr-group)#delete 4094 224.0.1.0
238.255.255.255
