lower active MD-level on the port.
None: No MHFs can be created for this VID.
For example:
Console(config-cfm-assoc)#add myassoc 1 4
none
To delete a registered association name.
For example:
Console(config-cfm-assoc)#delete myassoc
loopback <target mepid |
mac_address>[-n number(2-100)]
[-s size(1-255)] [-p priority(0-7)]
[-d drop_eligible(true | false)]
To configure loopback test settings.
For Example:
Console(cfm)#loopback domain assoc
00:01:02:03:04:05 -n 100 -s 255 -p 3 -d true
linktrace <target mepid |
mac_address> [-f flag(fdbonly |
none)][-h hop_count(1-255)]
To configure linktrace settings.
For Example:
Console(cfm)# linktrace domain assoc
00:01:02:03:04:05 -f none -h 100
de-measure <target mepid |
mac_address> [-n number(2-100)]
[-p priority(0-7)]
To configure delay measurement settings.
For Example:
Console(cfm)#de-measure domain assoc
00:01:02:03:04:05 -n 100 -p 0
Console(config-
dot1x-sys)#
To enable or disable 802.1X for the Managed
Switch.
RADIUS Authentication server address.
The identification word or number assigned to
each RADIUS authentication server with
which the client shares a secret.
<shared_secret>: up to 30 characters
reauth <enable | disable>
To enable or disable Reauthentication.
The time interval that the system sends out
periodic reauthentication message.
<reauth_period>: 0~3600 Seconds
eap-timeout <eapol_timeout>
The time that the Managed Switch waits for
responses from the server host to an
authentication request.
<eapol_timeout>: 1~255 Seconds
state <port_list> <auto | authorized
| unauthorized>
Specify each port‟s authentication statue.
<auto | authorized | unauthorized>:
Authorized: This forces the port to grant
access to all clients, either dot1x-aware or
otherwise. “Authorized” is the default setting.
Unauthorized: This forces the port to deny
access to all clients, either dot1x-aware or
otherwise.
