Microsens MS400870M Series User Manual

36
key <port_list> <key>
Specify the key value to the selected ports.
<port_list>: 1~26
<key>: The range of key value is from 0 to 255.
For example:
Console(config-aggr-lacp)# key 1-4,10-15,18,19
200
role <port_list> <active |
passive>
To set up whether LACP ports are active or
passive.
<port_list>: 1~26
<active | passive>: Active LACP ports are
capable of processing and sending LACP control
frames. This allows LACP compliant devices to
negotiate the aggregated link so that the group
may be changed dynamically as required. In
order to utilize the ability to change an aggregated
port group, that is, to add or remove ports from
the group, at least one of the participating devices
must designate LACP ports as active. Both
devices must support LACP.
LACP ports that are designated as passive
cannot initially send LACP control frames. In
order to allow the linked port group to negotiate
adjustments and make changes dynamically, one
end of the connection must have “active” LACP
ports.
For example:
Console(config-aggr-lacp)# role 1-4,10-15,18,19
active
2.6.2 CFM command mode
Prompt
Command & Parameter
Description
Console(config-
cfm-dom)#
add <domain_name> <level> <mhf>
This allows the user to register a CFM
maintenance domain.
<domain_name>: up to 22 characters.
<level>: 0~7
<mhf>: Specify MHF as “default” “explicit” or
“none”.
Default: MHFs can be created for this VID on
any Bridge Port through which the VID can
pass.
Explicit: MHFs can be created on CFM VLAN
member port and only if there is a MEP at the
lower active MD-level on the port.
None: No MHFs can be created for this VID.
For example:
Console(config-cfm-dom)#add mydomain 7
none
delete <domain_name>
To delete a registered domain name.
