Microsens MS400870M Series User Manual

41
Console(config-
mac)#
learning <port_list> <auto |
disable>
To set up each port‟s MAC learning function.
<port_list>: 1~26
For example:
Console(config-mac)# learning 1-4,10-15,18,19
auto
Console(config-
mac-static)#
add <mac-addr> <vlan_id> <port
| filter>
Specify a destination MAC address in the packet
and the VLAN where the packets with the
Destination MAC address can be forwarded.
<vlan_id>: 1~4094
<port | filter>: port:1~26 filter:27
delete <mac-addr> <vlan_id>
<port | filter>
Delete a MAC address setting.
2.6.7 Mirror command mode
Prompt
Command & Parameter
Description
Console(config-
mirror)#
port <mirror_port_list>
To enable or disable Target Port‟s mirroring on
the TX and RX of Source port.
<mirror_port_list>: 1~26
For example:
Console(config-mirror)# port 1-4,10-15,18,19
Target-port <target_port |
disable>
Specify the preferred target port for mirroring.
<target_port>: 1~26 or 0 (disabled)
For example:
Console(config-mirror)#target-port 24
2.6.8 MVR command mode
MVR refers to Multicast VLAN Registration that enables a media server to transmit multicast
stream in a single multicast VLAN when clients receiving multicast VLAN stream can reside
in different VLANs. Clients in different VLANs intend to join or leave the multicast group
simply by sending the IGMP Join or Leave message to a receiver port. The receiver port
that belongs to one of the multicast groups can receive multicast stream from the media
server.
MVR Configuration Guidelines and Limitations
Guidelines:
 Enable IGMP global setting.
 Enable MVR global setting.
 Create MVR VLAN and indicate the Source port and Receive port.
 Create MVR Groups whose multicasting channels would belong to MVR VLAN.
 Enable VLAN Aware in MVR Source Port. In a normal condition, Tag multicasting
stream injects to Source port. (Optional)
