47
<port_list>: 1~26
<path_cost>: 0~200000000
For example:
Console(config-rstp)# path-cost 1-4,10-15,18,19
100000
priority <port_list> <priority>
To specify each port‟s priority.
<port_list>: 1~26
<priority>: 0:0 1:16 2:32 3:48 4:64 5:80 6:96
7:112 8:128 9:144 10:160 11:176 12:192 13:208
14:224 15:240
For example:
Console(config-rstp)# priority 1-4,10-15,18,19 8
edge <port_list> <enable |
disable>
To enable or disable port edge.
<port_list>: 1~26
For example:
Console(config-rstp)# edge 1-4,10-15,18,19 enable
p2p <port_list> <forced_true |
forced_false | auto>
<port_list>: 1~26
<forced_true | forced_false | auto>: When
“forced_true” is selected, p2p ports will be forced to
turn on. Ports set as “Forced_false” will be forced
to turn off. “Auto” will detect the status
automatically.
For example:
Console(config-rstp)# p2p 1-4,10-15,18,19
forced_true
Console(config-
rstp-aggr)#
state <enable | disable>
To enable or disable RSTP state of aggregated
ports.
path-cost <path_cost>
To specify aggregated ports‟ path cost.
<path_cost>: 0~200000000
For example:
Console(config-rstp-aggr)# path-cost 100000
priority <priority>
To specify aggregated ports‟ priority.
<priority> : 0:0 1:16 2:32 3:48 4:64 5:80
6:96 7 112 8:128 9:144 10:160 11:176 12:192
13:208 14:224 15:240
For example:
Console(config-rstp-aggr)#priority 8
edge <enable | disable>
To enable or disable port edge.
p2p <forced_true |
forced_false | auto>
<forced_true | forced_false | auto>: When
“forced_true” is selected, p2p ports will be forced to
turn on. Ports set as “Forced_false” will be forced
to turn off. “Auto” will detect the status
automatically.
