Revision:1.0(2023-01-12)
117
Item Description
• Data source: used to obtain 3D/4D images for 4DViewer, which is
a private method of Mindray.
Storage Setting of
Structured Report
Set the structured report sending function.
Encapsulate PDF Select whether to encapsulate the measurement reports in PDF
format according to DICOM standards. If SCP supports this function,
then select it.
Key Image Marks After it is selected, only the images marked as key images will be
stored when you send and store them.
Sound
You can choose whether to store sound together when storing cine
files of PW mode.
Storage Mode Set the storage mode for images and cine files:
• Parallel file: Save the current file, and get ready for the storage of
the next file.
• Parallel frame: Send the current frame, and get ready for sending
the next frame.
Tracing with Probes After it is selected, if the images are transferred into DCM files
through DICOM or DICOMDIR, the files will include the serial number
of the probe.
Policy Name Set the DICOM policy.
• If the server software supports the compression algorithm, select JPEG, RLE, and
JPEG2000. Otherwise, Original data should be selected.
• Not all SCPs support RLE, JPEG, and JPEG2000. Please refer to the electronic file
DICOM CONFORMANCE STATEMENT of the SCP to check whether SCP supports or
not. Do not select these compression modes if the storage server doesn't support
them.
• Images of PW/M/TVM/TVD mode (B image is not frozen) and images other than PW/M/
TVM/TVD mode: If Max Frame rate is not Full and the actual frame rate is greater than
the set value, the system will save the image files in a frame rate of the set value, and
transfer in a frame rate of B mode.
• Images of PW/M/TVM/TVD mode (B image is frozen): The system will save or transfer
the images files in frame rate of 6.
Setting the Print Service
Diagnostic Ultrasound System
Service Manual
3 Installation
