Mindray TEX20 Service Manual

Revision:1.0(2023-01-12)
121
Item Description
Device Name After you set a server in DICOM Server Setting, the name will appear
in the drop-down list. Select the name of the storage commitment
server.
Service Name Specifies the service properties.
AE Title
Application entity title. Here, it should be consistent with that of the
storage commitment server.
Port
DICOM communication port. The default value is 104. Here, the port
should be set consistent with the storage commitment server port.
Maximum Retries Reserved function.
Interval Time (s) Reserved function.
Timeout Value: 5-60s, in increments of 5s, and 15s by default. After image
storage commitment is sent, the system will disconnect the server
after 15 seconds.
TLS Secure transmission layer protocol. Select whether to encrypt the
data transferred over the network.
Associated Storage
Service
Only after the associated storage server is set and the check is
completed, can storage commitment be sent.
• Set the associated storage server before performing the storage commitment service.
• The SCU port and the IP address set on the storage commitment SCP correspond to
those on the DICOM setting screen.
Query/Retrieve
Query/retrieve setting items are described as follows:
Item Description
Device Name
Select device names that can be added (including the local names).
Service Name Specifies the service properties.
AE Title Application entity title. Here, it should be consistent with that of the
storage commitment server.
Port DICOM communication port. The default value is 104. Here, the port
should be set consistent with the storage commitment server port.
Maximum Retries Reserved function.
Interval Time (s) Reserved function.
Diagnostic Ultrasound System
Service Manual
3 Installation
