Mindray TEX20

Revision:1.0(2023-01-12)
308
Table 8–3 Battery pack status indicators(continued)
Status
Indicator
Icon
Status Definition and Indication
2)The battery pack is available, AC is in
place, and the battery pack capacity <
95%: The status indicator is steady
orange.
3)The battery pack is available, AC is in
place, and the battery pack capacity ≥
95%: The status indicator is steady
green.
4)The battery pack is available, AC is not in
place, the main unit is powered on or in
the standby state, and the battery pack
capacity > 20%: The status indicator is
steady green.
5)The battery pack is available, AC is not in
place, the main unit is powered on or in
the standby state, and the battery pack
capacity ≤ 20%: The status indicator
blinks orange at the frequency of 0.8 Hz,
and the duty ratio is 50%.
6)The battery pack is available, AC is not in
place, the main unit is powered off, and
the battery pack capacity > 20%: The
status indicator is steady green.
7)The battery pack is available, AC is not in
place, the main unit is powered off, the
wireless probe charging base is in place
and in use, and the battery pack capacity
> 20%: The status indicator is steady
green.
8)The battery pack is available, AC is not in
place, the main unit is powered off, the
wireless probe charging base is in place
and in use, and the battery pack capacity
≤ 20%: The status indicator blinks orange
at the frequency of 0.8 Hz, and the duty
ratio is 50%.
Diagnostic Ultrasound System
Service Manual
8 Troubleshooting
