5)Tear off the release paper on the rear of the cushion pads. Cushion pads can be thick or thin
but with the same length and width. Observe the condition of the wall where the Charging Pile
module(China) is installed. If there is a skirting line at the bottom of the wall (the bottom
protrudes from the wall), use a thick cushion. If there is no skirting line at the bottom of the wall
(the wall surface is flat), use a thin cushion. It is specifically pasted in the pit in the red box, as
shown in the figure below.
6)Clean up the area on the ground where the module needs to be mounted, and then install the
module against the wall in the designated area. (Note: Mount it close to the socket.)
