Mitsubishi MELSEC Q Series User Manual

4
FUNCTIONS
4.4 MELSECNET/H Module Access Function
4.4.4 Link device refresh setting
4 - 30
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
FUNCTIONS
5
SETTING AND PROCEDURES
6
I/O NUMBER ASSIGNMENT
7
MEMORIES AND FILES
8
INSTALLING / UNINSTALLING
[Action 3: Reexamine the user program.]
Reexamine the task configuration, priority, processing details, etc. of the
user program in the C Controller module and make sure that the C
Controller system specifications and user program processing performance
are satisfied.
(c) Link device refresh cycle setting
Set the link device refresh cycle in "Link device refresh cycle" on the <<Parameter
setting>> tab. ( Section 9.4.6 (1))
Figure 4.26 Link device refresh cycle setting
Link device refresh cycle setting
