4.4 MELSECNET/H Module Access Function

4.4.3 Parameter setting

FUNCTIONS

4.4.3 Parameter setting

Set the parameters on the <<Parameter setting>> tab of the MELSECNET/H utility.

( Section 9.4.6)

Figure 4.18 Parameter setting screen
