17.2.4 Reusing preset multiple CPU parameters
Start
Start the C Controller setting utility.
Connect to the C Controller module.
(To next page)
Click the Import multiple CPU parameter
button on the <<Multiple CPU setting>> or
<<I/O assignment setting>> tab.
Setting of the project to be imported
Select the project in GX Developer whose
points occupied by empty slot, multiple CPU
setting, and I/O assignment is to be
imported.
Click the Open button.
Selecting "Yes" reads the empty slot point
setting, multiple CPU setting, and I/O
assignment setting data from the specified
project in GX Developer, and overwrites the
current settings with them.
