9.3.2 Operating Module information screen
The Module information screen displays various types of information of the CC-Link
module (self station) that is controlled by the connected C Controller module.
POINT
1. If a communication error has occurred during connection, click the
button or make the connection target setting again.
2. Communications are not available during reset of the C Controller module.
Start communications after terminating the reset process.
(1) Module information screen
Figure 9.51 Module information screen
Start monitor
