App - 10
Appendix 6 Parameter No. List
APPENDICES
Appendix 6 Parameter No. List
Parameter No. is displayed in event detail information screen of C Controller setting utility
when an error ( Section 18.3) occurs in parameter setting.
This appendix describes about the correspondence of a parameter Nos. to a parameter
setting locations.
(1) mn, **, N and M in the Parameter No. field
mn, **, N and M in the Parameter No. field indicate the following.
mn :
Indicates a "start I/O No. 16" value.
** : Indicates any value.
N : Indicates the module number.
M : Indicates the network type.
Table App.12 In the case of MELSECNET/H setting
M Network type
1H
MELSECNET/10 mode (Control station),
MELSECNET/H mode (Control station),
MELSECNET/H. Extended mode (Control station)
2H
MELSECNET/10 mode (Normal station),
MELSECNET/H mode (Normal station),
MELSECNET/H. Extended mode (Normal station)
5H MELSECNET/H (Remote master)
AH MELSECNET/H (Standby station)
BH MELSECNET/H mode multiplexed remote I/O network master station
DH
MELSECNET/H mode multiplexed remote I/O network sub-master station
(When there is no parameter setting)
EH
MELSECNET/H mode multiplexed remote I/O network sub-master station
(When there is parameter setting)
Table App.13 In the case of CC-Link setting
M Network type
0H Master station
1H Local station
2H Standby master station
To Next Page
