18.2.13 When operation is not normal due to script file execution
The following procedures disable the script file execution if the C Controller module does
not operate normally due to execution of the user program registered to the script file.
Figure 18.12 Flowchart for disenabling script file execution
Yes
No
No
Yes
Yes
No
Yes
No
Error occurred
Was the user program
started from a script file in the
CompactFlash card?
When the user program was started
from a script file in the standard ROM,
perform the following actions.
Save a script file from which the user
program will not start to the CompactFlash
card, set the CompactFlash card into the C
Controller module, and restart the C
Controller module.
Has the script file
execution stopped?
Remove the CompactFlash card from
the C Controller module.
Activate the default setting mode of the
hardware self-diagnostic function, and
restart the C Controller module.
Activation of the default setting mode
places the C Controller module in the
following status.
The IP address returns to the default
IP address.
The script file in the standard ROM
is deleted. ( Section 5.11)
Has the script file
execution stopped?
Consult your local Mitsubishi service
center or representative, explaining the
details of the problem.
Correct the script file in the standard
ROM, or correct the user program
started from the script file in the
standard ROM.
Correct the script file in the
CompactFlash card, or correct the user
program started from the script file in
the CompactFlash card.
Complete
Has the script file
execution stopped?
Remove the CompactFlash card, and
restart the C Controller module.
Section 5.10
