Mitsubishi MELSEC Q Series User Manual

9 - 134
9.5 Device Monitor Utility
9.5.1 Device monitor utility function list
9
UTILITY OPERATION
9.5 Device Monitor Utility
This section explains the operations of the Device monitor utility.
The following are the precautions for use of the Device monitor utility.
(1) While script file processing is being executed (the RUN LED is flashing), access may
not be made from each utility to the C Controller module.
In such a case, connect each utility to the C Controller module after terminating the
script file processing.
Remark
For the functions added to the Device monitor utility by version upgrade, refer to
Appendix 7.
9.5.1 Device monitor utility function list
The following is the Device monitor utility function list.
Table9.91 Function list of Device monitor utility
Name Description
Reference
section
Connection target setting Sets the connection target of the Device monitor utility. 9.1.3
Batch monitor Monitors only one specified device. 9.5.2
16-point register monitor
Monitors up to 5 bit devices and one word device at the
same time.
9.5.3
Setting monitoring target
Sets the network for which the Device monitor utility is
used.
9.5.4
Setting device to be
monitored
Sets the device to be monitored. 9.5.5
Changing word device value Changes the specified word device data. 9.5.6
Continuously changing word
device values
Changes the specified word device data for the set
points to the desired data.
9.5.7
ON/OFF of bit device Turns ON/OFF the specified bit device. 9.5.8
Changing the format Changes the format for device monitoring. 9.5.9
Start/stop monitor Sets start or stop monitoring of device monitor utility. 9.5.10
Numerical pad Enters a numerical value using a mouse. 9.5.11
