13.1 Mounting Position of CPU Module
When a multiple CPU system is configured, the combinations of the CPU modules shown
in Table13.1 are available
.
: Not available
(1) When CPU No. 1 is C Controller module
The mounting position of each CPU module is shown in Table13.2.
(a) Mounting position of C Controller module
Up to 4 C Controller modules can be mounted on the CPU slot (slot on the right
side of the power supply module) to Slot 2 of the main base unit.
(b) Mounting position of Motion CPU
Up to 3 Motion CPUs can be mounted on Slot 0 to Slot 2.
Table13.1 CPU module combinations
CPU No. 1
Number of CPU modules that can be mounted
as CPU No. 2 and later
Maximum number
of mounted
modules (including
CPU No. 1)
Reference section
High Performance
model QCPU
Motion CPU C Controller module
C Controller module 0 to 3 0 to 3 4 This section (1)
Basic model QCPU 0 to 1 0 to 1 3 This section (2)
High Performance
model QCPU
0 to 3 0 to 3 0 to 3 4 This section (3)
