13.1 Mounting Position of CPU Module
13
MULTIPLE CPU SYSTEM CONCEPT
* 1 The No. of CPUs indicates the value set in the "No. of CPU" on the <<Multiple CPU setting>> tab
of the C Controller Setting Utility.
Refer to the manuals of the corresponding CPU modules for the programmable controller CPU
and Motion CPU.
Table13.2 CPU module mounting position
No. of CPUs*
1
CPU module mounting position
2
3
4
CPU 0 1 2 3
: Slot numbe
r
CPU 0 1 2
Power supply module C Controller module C Controller module
CPU 0 1 2
Power supply module Motion CPU C Controller module
CPU 0 1 2
Power supply module C Controller module C Controller module C Controller module
CPU 0 1 2
Power supply module C Controller module C Controller module Motion CPU
CPU 0 1 2
Power supply module C Controller module C Controller module Motion CPU
CPU 0 1 2
Power supply module C Controller module Motion CPU Motion CPU
CPU 0 1 2
Power supply module C Controller module C Controller module C Controller module C Controller module
CPU 0 1 2
Power supply module C Controller module Motion CPU C Controller module C Controller module
CPU 0 1 2
Power supply module C Controller module Motion CPU C Controller module C Controller module
CPU 0 1 2
Power supply module C Controller module Motion CPU C Controller module C Controller module
CPU 0 1 2
Power supply module C Controller module Motion CPU C Controller module Motion CPU
CPU 0 1 2
Power supply module C Controller module Motion CPU C Controller module Motion CPU
CPU 0 1 2
Power supply module C Controller module Motion CPU C Controller module Motion CPU
CPU 0 1 2
Power supply module C Controller module Motion CPU Motion CPU Motion CPU
