4 - 1
4.1 Function List
4
FUNCTIONS
CHAPTER4 FUNCTIONS
This chapter explains the functions of the C Controller module.
4.1 Function List
The following lists the C Controller module functions.
(To next page)
Table4.1 C Controller module function list
Function Description
Reference
section
I/O module access function
Controls I/O modules and intelligent function
modules from the user program of the C Controller
module.
4.2
Intelligent function module access function
CC-Link module access function
Makes access via a CC-Link module controlled by
the C Controller module from the user program of
the C Controller module.
4.3
MELSECNET/H module access function
Makes access via a MELSECNET/H module
controlled by C Controller module from the user
program of the C Controller module.
4.4
Remote operation function
Controls the execution status of the C Controller
module from the user program of the C Controller
module and the development environment.
4.5
Self-diagnostic function
Self-diagnostic function
Monitors the operation status of each module and
displays error information, etc. at error occurrence.
4.6
Hardware self-diagnostic
function
Executes hardware self-diagnostics according to the
setting in the hardware self-diagnostic operation
mode.
18.5
Output (Y) setting at switching from STOP to RUN
Sets the output (Y) status for the case where the
STOP status is switched to the RUN status.
4.7
Clock function
Reads the clock data in the C Controller module
with the user program and uses them for time
control.
4.8
Input response time selection
Selects the response time for the Q series input
module, I/O composite module, Hi. speed input
module or interrupt module.
4.9
Error time output mode setting
Sets whether to clear or hold the outputs to output
modules, I/O composite modules and intelligent
function modules when a stop error occurs in the C
Controller module.
4.10
Hardware error time CPU operating mode setting
Sets whether to stop or run the C Controller module
when a hardware error occurs in the intelligent
function module.
4.11
