9 - 60
9.3 CC-Link utility
9.3.2 Operating Module information screen
9
UTILITY OPERATION
* 1 The module information data are displayed at once in ascending order of the start I/O No.
(a) Operating modes
The following indicates the details of the operating modes.
Table9.34 Explanation of Module information screen
Item Description
Target module
Select the CC-Link module whose module information will be displayed.
(Initial value: "1-4 slot", Setting range: "1-4 slot", "5-8 slot")
n slot
*1
(n is within the range set to
"Target module".)
Displays various types of the CC-Link module information.
Start I/O No. Displays the start I/O No. of the CC-Link module.
Channel No.
Displays the channel No. of the CC-Link module where parameter setting has been
made.
"-" appears when the "channel No." has not been set in the parameter.
Sta. No.
Displays "<Sta. No.>: <Station type><Operation mode>".
The display range of <Station number> is "0" to "64", and <Station type> is displayed as
"Master station" or "Local station".
Refer to the following for details of <Operation mode>.
This section (1)(a)
(Display example: "0: Master station (Ver. 2 mode)", "1: Local station")
Data link status
Displays the data link status of the CC-Link module. (
This section (1)(b))
Link scan time Displays the present link scan time of the CC-Link module. (units of ms )
Error status
Displays the error status of the CC-Link module. (
This section (1)(c))
button
Opens the "Module detail information" screen. ( This section (2))
While monitoring is stopped, the button cannot be clicked.
button
Starts monitoring of the CC-Link module.
During monitoring, this button changes to , and "*" flashes at top right of the
button.
In an offline status, this button cannot be clicked.
button
Stops monitoring of the CC-Link module.
When monitoring is stopped, this button changes to .
Table9.35 Details of operating modes
Display Description
No display
Cyclic transmission data size has not been increased.
Remote net (Ver.1 mode)
(Additional mode)
There are both CC-Link modules supporting the increase of
cyclic transmission data size and those not supporting it.
Remote net (Add.mode)
(Ver.2 mode)
Cyclic transmission data size has been increased.
Remote net (Ver.2 mode)
Module information
Other station monitor Online operation Parameter setting Target setting Test
Details
Details
Start monitor
Stop monitor
Stop monitor
Start monitor
