UTILITY OPERATION
9.3 CC-Link utility
9.3.2 Operating Module information screen
9 - 61
9
UTILITY OPERATION
10
FUNCTIONS AND
PROGRAMMING
11
OVERVIEW OF
MULTIPLE CPU
SYSTEM
12
MULTIPLE CPU
SYSTEM
CONFIGURATION
13
MULTIPLE CPU
SYSTEM
CONCEPT
14
COMMUNICATIONS
BETWEEN CPU
MODULES
15
PARAMETERS
ADDED FOR
MULTIPLE CPU
16
PRECAUTIONS FOR
USE OF AnS SERIES
MODULE
(b) Details of data link status
The following indicates the details of the data link status.
Table9.36 Details of data link status
Display Description
In data link Data link is being executed.
Suspended data link Data link is suspended.
Initial status In initial status (before parameter update).
Waiting for receiving
parameters
Parameters have not been received.
Disconnecting (no request
polling)
Disconnected from data link network without inquiry
from the master station.
Disconnecting (link error) Disconnected from data link network due to a line error.
Disconnecting (other)
Disconnected from data link network due to any other
factor.
During line test Line test is being executed.
During parameter setting test
Parameter setting test is being executed from the
master station.
During auto-Returning
Processing for automatically returning to data link
network is being performed.
During reset CC-Link module is being reset.
