4 - 45
4.5 Remote Operation Function
4.5.2 Remote PAUSE
4
FUNCTIONS
(b) Using development environment (personal computer)
On the <<Online operation>> tab of the C Controller setting utility, select "PAUSE"
for "Remote operation" and click the button.
(4) Precautions
The user program will not stop even if the C Controller module is put in a remote
PAUSE status. (Operation continues in the C Controller module.)
When changing the program processing according to the operation status of the C
Controller module, perform programming utilizing the bus interface function
(QBF_ReadStatusEx function).
Remark
The C Controller module operation status can be verified by the following:
• Bus interface function (QBF_ReadStatusEx function)
• C Controller setting utility ("CPU operation status" on <<Module
information>> tab)
Figure 4.39 Remote PAUSE from development environment (personal computer)
Execution
2) Click
Execution button.
1) Set to "PAUSE".
To Next Page
