4 - 47
4.5 Remote Operation Function
4.5.3 Remote RESET
4
FUNCTIONS
(5) Confirmation before remote RESET
(a) When the C Controller module is used in a single CPU system, or used as
CPU No.1 in a multiple CPU system
Before executing remote RESET, check the following conditions 1) to 2).
Remote RESET is not allowed if any of the conditions 1) to 2) are not satisfied.
1) Setting required for remote reset
"Remote reset" must be set to "Allow" on the <<System setting>> tab of the C
Controller setting utility, and parameters must have already been written to the
C Controller module. (Reset the C Controller module after writing the
parameters.)
2) C Controller module status
The C Controller module should be in the STOP status.
Figure 4.40 Setting remote reset to Allow
Set to "Allow".
