Mitsubishi MELSEC Q Series User Manual

6 - 27
6.7 I/O Number Assignment Examples
6
I/O NUMBER ASSIGNMENT
(b) I/O assignment with C Controller setting utility
Set "200" to Slot No.3 and "70" to Slot No.4 on <<I/O assignment setting>> tab of
the C Controller setting utility.
(c) I/O number assignment after change with C Controller setting utility
Figure 6.23 I/O assignment (When changing I/O numbers of Slot 3)
Figure 6.24 I/O number assignment (After changing slot I/O numbers)
"200" is specified as the
start I/O number.
"70" is specified as the
start I/O number. (When
the start I/O number is
not specified, the I/O
number following the 3rd
slot will be assigned.)
Extension 1
to toto
to to to toto
to toto
to to to toto
Q38B
Q68B
012 45673
X00 X20 X40 Y70 Y90 YB0 YD0X200
X1F X3F X5F Y8F YAF YCF YEFX21F
8 9 10 12 13 14 1511
F0 110 130 170 Y180 Y1A0 Y1C0150
10F 12F 14F 17F Y19F Y1BF Y1DF16F
Input module Input module Input module Input module
Output module Output module Output module Output module
32
points
32
points
32
points
32
points
32
points
32
points
32
points
32
points
Number of
I/O points
Slot number
I/O number
Intelligent function module Intelligent function module Intelligent function module Intelligent function module
Empty
Output module Output module Output module
32
points
32
points
32
points
16
points
32
points
32
points
32
points
32
points
