9 - 14
9.2 C Controller Setting Utility
9.2.2 Operating Module information screen
9
UTILITY OPERATION
* 1 The displayed "Used space" of the "Standard ROM information" and "CF card information"
includes the size used by the file system.
Table9.7 Explanation of Module information screen
Item Description
Reference
section
Module information Displays the information of the C Controller module.
LED information
Displays the LED status of the C Controller module.
Note that the CH2 SD/RD indication is invalid.
5.4 (1)
Toggle switch information
Displays the RUN/STOP/MODE switch and RESET/SELECT switch
statuses of the C Controller module.
5.4 (2)
CPU operation
Displays the operation status ("RUN", "STOP", "PAUSE") of the C
Controller module, including remote operation.
4.5
Error code Displays the latest error code among the past stop/continue errors. 18.3
Error information
When a stop/continue error has occurred in the C Controller module, the
corresponding stop/continue error item changes from (White) to
(Red).
18.3
button
Starts monitoring.
During monitoring, this button changes to , and "*" flashes at
top right of the button.
In an offline status, this button cannot be clicked.
button
Stops monitoring.
When monitoring is stopped, this button changes to .
Drive information Displays the drive information of the C Controller module.
Standard ROM information
Displays the entire space, used space and free space of the standard
ROM.
*1
7.1
CF card information
When a CompactFlash card is not installed, displays "Empty". When a
CompactFlash card is installed, displays the entire space, used space
and free space of the CompactFlash card.
*1
7.1
button
Updates the "Standard ROM information" and "CF card information".
Module information
Event history SRAM monitor Module monitor Online operation
Start monitor
Stop monitor
Stop monitor
Start monitor
Update
