9 - 68
9.3 CC-Link utility
9.3.3 Operating Other station monitor screen
9
UTILITY OPERATION
(b) Status details
The following indicates the details of the statuses.
(c) Details of reserved station
The following indicates the details of the reserved station.
(d) Details of error invalid station information
The following indicates the details of the error invalid station.
(e) Details of transient error
The following indicates the details of the transient error.
Table9.42 Status details
Display Description
Normal Normal
Temporary error invalidity status Temporary error is treated as invalid.
Data link error Link status is in error.
WDT error Watchdog timer error occurred.
Blown fuse confirmation error There is a station that has the fuse blown.
Repetition station No. Station number is duplicated.
Switch changing Switch setting was changed.
Table9.43 Details of reserved station
Display Description
Reserved station Reserved station status is set.
No setting
Table9.44 Details of error invalid station
Display Description
Error invalid station Error invalid station status is set.
No setting
Table9.45 Details of transient error
Display Description
Transient transmission error Error identified
No error
To Next Page
