Mitsubishi MELSEC Q Series User Manual

9 - 142
9.5 Device Monitor Utility
9.5.6 Changing word device values
9
UTILITY OPERATION
(1) Menu item to be selected
Select [Device Write] [Data changing] from the menu bar.
(2) Dialog box
Figure 9.106 Data Changing dialog box
Table9.96 Explanation of Data Changing dialog box
Item Description
Device Type
Set the type, block No., and network No. of the device whose data will
be changed. ( Section 10.3.11)
Device No.
Set the start No. of the device whose data will be changed.
(HEX: Hexadecimal, DEC: Decimal, OCT: Octal)
Setting Data Set new data. (HEX: Hexadecimal, DEC: Decimal)
