FUNCTIONS AND PROGRAMMING
10.1 Outline of Functions
10 - 2
9
UTILITY OPERATION
10
FUNCTIONS AND PROGRAMMING
11
OVERVIEW OF MULTIPLE CPU SYSTEM
12
MULTIPLE CPU SYSTEM CONFIGURATION
13
MULTIPLE CPU SYSTEM CONCEPT
14
COMMUNICATIONS BETWEEN CPU MODULES
15
PARAMETERS ADDED FOR MULTIPLE CPU
16
PRECAUTIONS FOR USE OF AnS SERIES MODULE
Table10.1 Access targets of bus interface functions by applications
Arrow Access target
Application
given above
Access from C
Controller setting
utility
Setting of Device
monitor utility
Remarks
Input module/output module 1) Accessible Not available
Input (X) : Monitoring
enabled
Output (Y) : Monitoring and
forced output
enabled
Intelligent function module 2) Accessible Not available
Monitoring and forced
writing of buffer memory
enabled
Programmable controller
CPU/Motion CPU
3) Not accessible Not available
MELSECNET/H module
(other station)
4) Not accessible Not available
MELSECNET/H module
(self station)
5) Not accessible Not available
C Controller module 6) to 12) Accessible Not available
The following operation
can be performed.
• Remote RUN/STOP/
PAUSE
• Setting and reading of
clock data
• Write and read of data to
and from battery-backed-
up RAM
