(10)A variety of CC-Link products can be controlled
The C Controller module can control a variety of CC-Link products by user programs.
Up to eight CC-Link modules can be installed.
(11)Easy creation of Ethernet communication program
The C Controller module has the 10BASE-T/100BASE-TX port.
Using the VxWorks communication library (socket communication functions), Ethernet
communication programs can be created.
Figure 1.13 CC-Link product control
Figure 1.14 Ethernet communications using 10BASE-T/100BASE-TX port
Remote I/O station
Remote device station
Intelligent device station
Local station
Partner manufacturer's
product
CC-Link module
C Controller module
C Controller module
Ethernet communications
