12 - 20
12.3 Precautions for System Configuration
12
MULTIPLE CPU SYSTEM CONFIGURATION
(c) When CPU No. 1 is High Performance model QCPU
* 1 This module cannot be set to the control CPU since it is not applicable to the C Controller module.
* 2 The C Controller module can control up to 8 CC-Link modules.
* 3 For the available GOT model name, refer to the following manuals.
GOT-A900 Series User's Manual (GT Works2 Version2/GT Designer2 Version2 compatible
Connection System Manual)
GOT1000 Series Connection Manual
Table12.10 Modules having restrictions on the number of mounted modules
Product Model name
Limit on number of mounted modules
per system
Limit on number of mounted
modules per CPU
Q series MELSECNET/H
network module
• QJ71LP21
*1
• QJ71BR11
• QJ71LP21-25
• QJ71LP21S-25
• QJ71LP21G
• QJ71LP21GE
Up to a total of 4 modules on PLC-to-
PLC network/remote I/O network
Up to a total of 4 modules on
PLC-to-PLC network/remote I/O
network
Q series Ethernet interface
module
*1
• QJ71E71
• QJ71E71-B2
• QJ71E71-B5
• QJ71E71-100
Up to 4 modules Up to 4 modules
Q series CC-Link system
master/local module
• QJ61BT11
• QJ61BT11N
No limit
*2
No limit
AnS series special function
module
*1
• A1SJ71PT32-S3
• A1SJ71T32-S3
No limit
(Note that auto refresh function cannot
be set)
No limit
(Note that auto refresh function
cannot be set)
• A1SD51S
• A1SD21-S1
• A1SJ71J92-S3
(When GET/PUT service is
used)
Up to a total of 6 modules Up to a total of 6 modules
Interrupt module
•A1SI61
*1
Only 1 module
Only 1 module
•QI60
Up to 4 modules
(Up to 3 modules when A1SI61 is used)
GOT
• GOT-A900 series (Bus
connection only)
*3
• GOT1000 series (Bus
connection only)
*3
Up to 5 modules
Up to 5 modules
