TROUBLESHOOTING
18.3 Actions for Lit/Flashing ERR. LED
18 - 21
17
STARTING MULTIPLE CPU SYSTEM
18
TROUBLESHOOTING
APPENDICESINDEX
Remark
Refer to Section 4.6 for details of the self-diagnostic items.
Table18.2 Self-diagnostics and error codes (Continued)
Error item Self-diagnostic item Description
Error
code
Intelligent function
module assignment error
Intelligent function
module assignment error
detection
An error occurred during diagnosis of the intelligent
function module I/O assignment status.
2100
2103
2106
2107
2108
2120
2121
2122
2124
2125
2126
2150
Parameter error
Parameter error
detection
An error occurred during parameter diagnosis of the
system setting, multiple CPU setting, etc.
2200
3000
3001
3010
3012
3014
Intelligent function
module parameter error
Intelligent function
module parameter error
detection
An error occurred during diagnosis of the intelligent
function module parameters.
3300
3301
3302
3303
Link parameter error
Link parameter error
detection
An error occurred during diagnosis of the network module
(CC-Link module, MELSECNET/H module) parameters.
3100
3101
3102
3103
3104
3105
3107
Multi CPU error Multi CPU error detection
Another CPU error or multiple CPU system error was
detected in a multiple CPU system configuration.
7000
7002
7010
7020
Other Other error detection A stop/continue error other than the above was detected.
1510
1520
2502
5012
