18.4 Error Code and Error Message Lists
18.4.1 Actions by error codes generated at function execution
18
TROUBLESHOOTING
(To next page)
Table18.8 Common error codes returned by bus interface functions and MELSEC data link functions (Continued)
Return value
(HEX)
Error description Corrective action
19458
(0x4C02)
The Motion SFC program No. to start is outside the range 0 to 255
(the error code returned by the Motion CPU).
Refer to the manual of used Motion CPU.
Check the user program on C Controller module.
19460
(0x4C04)
Axis No. set by SVST instruction is injustice. (the error code
returned by the Motion CPU)
Refer to the manual of used Motion CPU.
Check the user program on C Controller module.
19461
(0x4C05)
Axis No. set by CHGA instruction is injustice. (the error code
returned by the Motion CPU)
Refer to the manual of used Motion CPU.
Check the user program on C Controller module.
19462
(0x4C06)
Axis No. set by CHGV instruction is injustice. (the error code
returned by the Motion CPU)
Refer to the manual of used Motion CPU.
Check the user program on C Controller module.
19463
(0x4C07)
Axis No. set by CHGT instruction is injustice. (the error code
returned by the Motion CPU)
Refer to the manual of used Motion CPU.
Check the user program on C Controller module.
19464
(0x4C08)
There are 32 or more instruction requests to the Motion CPU from
the programmable controller CPU / C Controller module in sum
table simultaneously, and the Motion CPU cannot process them.
(the error code returned by the Motion CPU)
Refer to the manual of used Motion CPU.
Check the user program on C Controller module.
19465
(0x4C09)
CPU No. of the instruction cause is injustice. (the error code
returned by the Motion CPU)
Refer to the manual of used Motion CPU.
Check the user program on C Controller module.
19584
(0x4C80)
H/W error of the target CPU (the error code returned by the
Motion CPU)
Check the operation state of the target CPU.
Deal according to the manual of the target CPU.
19585
(0x4C81)
H/W error of the target CPU (the error code returned by the
Motion CPU)
Check the operation state of the target CPU.
Deal according to the manual of the target CPU.
19587
(0x4C83)
H/W error of the target CPU (the error code returned by the
Motion CPU)
Check the operation state of the target CPU.
Deal according to the manual of the target CPU.
19588
(0x4C84)
H/W error of the target CPU (the error code returned by the
Motion CPU)
Check the operation state of the target CPU.
Deal according to the manual of the target CPU.
-475(0xFE25)
to
-3839(0xF101)
Q Corresponding MELSECNET/H Network System
Reference Manual (PLC to PLC network)
For QnA/Q4AR MELSECNET/10 Network System
Reference Manual
Type MELSECNET/10 Network system (PLC to PLC
network) Reference Manual
Same as in the left
-2174
(0xF782)
Destination station number specification error
The destination station number for the processing request is
specifying the own station.
Check the specified station number.
Check if the station number 255(0xFF) is specified
to the own station.
-16386(0xBFFE)
to
-20222(0xB102)
CC-Link System Master/Local Module User's Manual
Control & Communication Link System Master/Local
Module type AJ61QBT11/A1SJ61QBT11 User's Manual
Control & Communication Link System Master/Local
Module Type AJ61BT11/A1SJ61BT11 User's Manual
Same as in the left
-18558
(0xB782)
Destination station number specification error
The destination station number for the processing request is
specifying the own station.
Check the specified station number.
