18
TROUBLESHOOTING
18.4 Error Code and Error Message Lists
18.4.1 Actions by error codes generated at function execution
18 - 45
17
STARTING MULTIPLE CPU SYSTEM
18
TROUBLESHOOTING
APPENDICESINDEX
* 1 In a single CPU configuration, reset the C Controller module.
In a multiple CPU configuration, reset CPU No.1.
(2) Error codes returned by bus interface functions
The following provides the error descriptions and corrective actions corresponding to
individual error codes returned when the bus interface functions are executed.
Refer to this section (1) for the common error codes returned by bus interface
functions and MELSEC data link functions.
(To next page)
Table18.8 Common error codes returned by bus interface functions and MELSEC data link functions (Continued)
Return value
(HEX)
Error description Corrective action
-28663
(0x9009)
Base number specification error
The specified base number Is out of range.
Check the specified base number.
-28664
(0x9008)
Data transmission area occupied error Retry.
-28665
(0x9007)
No registration data error
Reboot the system.
*1
-28666
(0x9006)
Data length error
Reboot the system.
*1
-28668
(0x9004)
Reply data stored error Demand once again.
-28669
(0x9003)
Area number error
The specified area number or offset address or mode is out of range.
Check the specified area number or offset
address or mode.
-28671
(0x9001)
Module identification error
Check the parameter.
Check the specified module.
Reboot the system.
*1
-28672
(0x9000)
Processing code error
Install software package again.
Reboot the system.
*1
Table18.9 Error codes returned by bus interface functions
Return value
(HEX)
Error description Corrective action
0 Normal completion
-201
(0xFF37)
Module identification error
The specified module identification is invalid.
Check the specified module identification.
-202
(0xFF36)
Path error
The specified path is invalid.
Use the path pointer returned with
"QBF_Open".
-203
(0xFF35)
Input number/output number error
The specified input number/output number is out of range.
Check the specified input number/output
number.
-204
(0xFF34)
I/O Access size error
The specified I/O number + size is out of range.
Check the specified I/O access size.
Check the I/O number + size.
-205
(0xFF33)
I/O number error
The specified I/O number is out of range.
Check the specified I/O number.
-206
(0xFF32)
Program execution type error
The specified program execution type is out of range.
Check the specified program execution type.
-208
(0xFF30)
Offset error
The specified offset is out of range.
The specified I/O number is AnS series module.
Check the specified offset.
Check the specified I/O number.
-209
(0xFF2F)
Buffer memory size error
The specified offset + size is out of range.
The address of specified data stored buffer pointer is 0.
Check the specified buffer memory size.
Check the offset + size.
Check the data stored buffer pointer.
-210
(0xFF2E)
Read area size error
The read area is too small.
Check the read size and read area size.
