Keep the filter disabled until all the other parameters of the filter are entered.
You must enter the parameters in the following order:
1. Damping
2. Frequency
3. Filter type
Examples of filters
Example of a Notch filter configuration: insert a Notch filter centered at 30 Hz.
Example configuration of a low pass filter of 2nd order.
PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
Filter configuration
101
