WARNING: Electrical hazard - AVERTISSEMENT: risque électrique
High voltage may be present, which can result in death or serious injury to
personnel, or damage to equipment.
Ø If the connection cables of the STO function are located beyond the area of the
machine installation, the cables must be installed in a "fixed" manner and pro-
tected (for example through a raceway).
5.3.6.10 Transducer Connection
The DM2020 is able to handle most of the common position motor transducers in the table below:
PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
5.3.6.10 Transducer Connection
Resolver X3- / X13
Stegmann absolute single-turn sinusoidal encoder with/without hiperface X2-X12
Stegmann absolute multi-turn sinusoidal encoder with/without hiperface X2-X12
Heidenhain absolute single-turn sinusoidal encoder with EnDAT/without EnDAT X2-X12
Heidenhain absolute multi-turn sinusoidal encoder with EnDAT/without EnDAT X2-X12
Heidenhain EnDAT 21 or 22 full digital encoder X2-X12
Heidenhain linear encoder with EnDAT X2-X12
TTL incremental encoder X1-X11
CAUTION
The cable for the incremental encoder must be composed of at least six individually shielded twisted
pairs for the encoder signals
INFORMATION
Contact the Applications Service for connections longer than 50 m
