Moog DM2020 Series User Manual

PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
3.2.3.7Connector view
X1 - X11
Opzionale
X2 - X12
X3 - X13
X4 - X14
X5 - X15
X6 - X16
X7 - X17
X21
X20
X19 X18
X8 - X9
X10A - X10B
Bus Bar
0 V0 Voolltt
+ + DDC bC buuss
- - DDC bC buuss
GND GND (T(Teerrrra)a)
++224 V4 Voolltt
Bus Bar
}
(A)
(B)
Dual-axis module: View from the front (A) and bottom (B)
Note that the arrangement of the connectors remains unchanged in the L75 and L100 sizes
(front and bottom) and L200 (only front see next page for the bottom).
3.2.7.3 Connector view
44
