Moog DM2020 Series User Manual

l
Displays on the GUI: the data are only displayed and not recorded
l
Save Locally: the data are displayed and saved on the PC in the directory specified in Output
Folder
To start recording, click Start; to stop recording, click Stop.
6.8.3 View Logs
Select the View tab.
After acquisition, the data is shown on the display.
PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
6.8.3 View Logs
On the top left are the Cursor Activation (Cursor) and Displacement of the Graph (Pan) functions.
Magnification of the details (Zoom) and printing of the image (Screenshot); mouse cursor shall show
the legend of the 4 buttons when hovering above them.
If the Auto Range check box is selected, each signal is shown in the window; otherwise, the data
appear at the acquired scale unless you modify them with the Amplitude command.
115
