3.1.2 Storage and Working Conditions
PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
3.1.2 Storage and Working Conditions
Ambient operating
temperature
from 0 °C to 40 °C
up to 55 °C with an output current reduction (-2%/°C)
Storage temperature from -25 °C to 55 °C
Transport temperature from -25 °C to 70 °C
Humidity permitted
during operation
5…85%
Condensate not permitted
Humidity permitted in storage 5…95 %
Humidity permitted for
transport
95% at 40 °C
Assembly height
Up to 1000 m above AMSL, over 1000 m above AMSL with reduced
current (-2%/100 m) max. 2000 m above AMSL
Certification CE, UL (E194181), EAC
IP protection rating IP20
Pollution
degree
2 or less (only non-conductive pollution is usually permitted. Temporary
conductivity caused by condensation may occasionally be expected, but only
when the drive is not in operation or attached to a power supply)
Mechanical resistance in
compliance with EN
60721-3-3
Vibration: 3 mm for frequencies between 2…9 Hz
Vibration: 9.8 m/s
2
(1 g) for frequencies between 9 and
200 Hz Shock: 98 m/s
2
(10 g) for 11 ms
Machine safety STO (Safe Torque Off) SILCL 3 PL “e” (as certiied below)
Model/Code CC201xxxxx CC202xxxxx
Mechanical dimensions
50 mm/1.97 inches 150 mm/5.9 inches
Type
L50
L150
Electrical line power supply
3-phase, from 200 to 528 V AC, 50/60 Hz
Auxiliary busbar power supply
24 V DC +/- 10% (supplied externally)
Arms rated current
54 128
Arms peak current
130 256
Protection
NTC and bi-metallic thermal protection to 85 °C
Detection of loss during input phase
Detection of insuficient input voltage or overvoltage
Communication
CANopen for sharing data with the drives
Cooling
Incorporated ventilation
Weight (kg)
5.1 13.5
Connector code
BC0004R BC0006R
The power supply model code is shown on two plates: One located on the front above the protector for the
module's terminal block and the other on the right-hand side of each axis module.
To request any kind of information about a specific p
ower supply, the details on the side plate identifying each
individual power supply must be communicated to Moog-Casella.
3.1.3. Standard power supply models
