3.2.4 Connectors
PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
3.2.3Connectors
0 Volt
+ DC bus
- DC bus
GND
X1
Brake resistor
X2 Power connector
+24 Volt
Bus Bar
}
Status Led
CAN connectors
(Earth)
38
